Sony 10-18mm chromatic aberration?

Welcome to the New Sony Alpha Shooters Community
Our community was only launched in August 2020 but is already thriving thanks to many amazing and helpful members. We'd love to welcome you on board too!
Join Now

FowlersFreeTime

Well Known Member
Original poster
Pro Member
Pro Member
Followers
10
Following
3
472
251
Nov 19, 2020
Name
Chris Fowler
Country
United States
City/State
Pembroke Pines/FL
What causes chromatic aberration? I did lens correction and a quick auto edit for demonstration purposes: Pixel peep the highlights for some extreme purple fringing.
Is this because I took the pictures hand-held? I'm definitely less than impressed with this f4 lens in low-light conditions; I think the Sigma 16mm would have performed better.

DSC04505.jpg DSC04506.jpg


Ivanturas

Active Member
Pro Member
Pro Member
Followers
1
Following
0
67
20
Nov 17, 2020
Name
Iván Fuentes Hagar
Chromatic aberration occurs due to light being diffracted unevenly along different wavelenghts. That means some frequencies will hit the sensor on different spots, although they actually originated from the same place.

Wide angle lenses tend to be more prone to this, especially the closest you get to the borders, due to obvious reasons. Also, different apertures will provide different results, the more elements your lens has, the more chances you get to acquiring aberration, and that also brings us last but not least, zoom lenses also raise the stakes.

Aberration is quite easy to correct in post, though... especially if shooting RAW, and even more if you have your lens profile loaded, since the it becomes a matter of just "realigning" channels the proper way, in the proper spots.


tcoquelin

Active Member
Pro Member
Pro Member
Followers
0
Following
0
38
29
Aug 29, 2020
It looks like LCA (longitudinal chromatic aberration). You can think of it as bokeh fringing. If you take the same picture at f8, the purple fringe should almost disappear
Edit after zooming in more:
I looks more like TCA (transversal chromatic aberration), so closing the lens more should not make any difference. They can be automatically and efficiently fixed in post.

Last edited:

FowlersFreeTime

Well Known Member
Original poster
Pro Member
Pro Member
Followers
10
Following
3
472
251
Nov 19, 2020
Name
Chris Fowler
Country
United States
City/State
Pembroke Pines/FL
Chromatic aberration occurs due to light being diffracted unevenly along different wavelenghts. That means some frequencies will hit the sensor on different spots, although they actually originated from the same place.

Wide angle lenses tend to be more prone to this, especially the closest you get to the borders, due to obvious reasons. Also, different apertures will provide different results, the more elements your lens has, the more chances you get to acquiring aberration, and that also brings us last but not least, zoom lenses also raise the stakes.

Aberration is quite easy to correct in post, though... especially if shooting RAW, and even more if you have your lens profile loaded, since the it becomes a matter of just "realigning" channels the proper way, in the proper spots.
I did the lens correction and CA reduction in Adobe, what you're seeing is after that! Crazy right?


FowlersFreeTime

Well Known Member
Original poster
Pro Member
Pro Member
Followers
10
Following
3
472
251
Nov 19, 2020
Name
Chris Fowler
Country
United States
City/State
Pembroke Pines/FL
It looks like LCA (longitudinal chromatic aberration). You can think of it as bokeh fringing. If you take the same picture at f8, the purple fringe should almost disappear
I wish I had a tripod at the time, I would have used f8 and a longer exposure for sure.
